QBC Crystal UHD Samsung Digital Signage

Shine Your Business Message with Crystal UHD Signage

Introducing the QBC series which is the slimmest UHD Samsung Signage. The Samsung QBC Series is crafted for businesses seeking impactful visuals in a sleek, space-saving package. Combining advanced UHD resolution with an ultra-slim profile, this digital display offers excellent performance for commercial environments, such as retail stores, corporate offices, and hospitality venues. The QBC offers six different size variants i.e., 43, 50, 55, 65, 75, and 85 inch.

Samsung Digital Signage QBC Series

LH75QBCEBGCX

QBC Series Available in Different Variants

Samsung QBC 43" Crystal UHD Digital Signage

Samsung QBC 50" Crystal UHD Digital Signage

Samsung QBC 55" Crystal UHD Digital Signage

Samsung QBC 65" Crystal UHD Digital Signage

Samsung QBC 75" Crystal UHD Digital Signage

Samsung QBC 85" Crystal UHD Digital Signage

Slim Design with Maximum Impact

The QBC is Samsung’s slimmest UHD signage display, measuring just 28.5mm in depth. It offers a modern, minimalist aesthetic that fits seamlessly into any space. Compatible with the Slim Fit Wall Mount (sold separately), this display allows for easy, flush installation without compromising elegance or efficiency.

Vibrant, True-to-Life Colors

The Dynamic Crystal Color technology of Samsung delivers over a billion shades of color, that result in the creation of vibrant imagery. This ensures your brand visuals, advertisements, and presentations stand out with precise color reproduction. Combined with 4K UHD resolution (3840 x 2160), the display provides remarkable clarity and detail, enhancing customer engagement.

Versatile Orientation with Even Bezels

The QBC Series features even bezels on all sides, ensuring consistent framing whether the screen is used in landscape or portrait mode. This uniform design minimizes distractions and makes the screen ideal for multi-display setups in video walls or dynamic signage configurations.

Enhanced Usability with Tizen OS and Home UI

Powered by Tizen OS 7.0, the QBC offers a user-friendly interface with an intuitive home screen. Key categories such as Favorites, Sources, and Settings are easily accessible, streamlining operations. The display also supports Samsung’s Smart Calibration through a mobile app, ensuring consistent color accuracy across all installations.

Professional-Grade Tools and Modes

This display includes specialized modes for industry-specific needs. The Director Mode ensures content is displayed as originally intended, without post-processing, while the DICOM Simulation Mode supports medical professionals by accurately presenting grayscale images, such as X-rays, meeting DICOM standards.

Remote Management and Smart Content Solutions

The QBC integrates with Samsung VXT, a cloud-based CMS (Content Management System) that simplifies remote management. Users can adjust hardware settings, deploy content, and troubleshoot issues remotely—no technical expertise required. VXT CMS (available separately) ensures seamless management across multiple locations.

Secure and Mounting

The Centered VESA holes add to the strong mounting of QBC. The VESA holes are right in the center of the display, which makes mounting a breeze by evenly distributing the weight. With this setup, you can easily switch to portrait mode without worrying about the screen tilting or feeling off-balance. It’s all about giving you that extra stability and flexibility!

Comprehensive Connectivity Options

This display is equipped with three HDMI ports, USB connectivity, Bluetooth, and Wi-Fi to support various input sources. The RJ45 and RS232 ports enable reliable network integration and remote control for commercial applications.

Energy Efficiency and Sustainability

The QBC Series promotes environmental responsibility with Energy Star 8.0 and EPEAT certifications for energy efficiency and eco-conscious practices, such as using recycled plastics. This makes QBC an ideal choice for businesses committed to sustainable technology.

Specifications

VA

Panel Type

350nit

Brightness

3,840 x 2,160

Resolution

8ms

Response Time

Display

Diagonal Size: 43″/50″/55″/65″/75″/85″
Panel Type: VA
Resolution: 3,840 x 2,160
Brightness (Typ): 350 nit
Contrast Ratio: 4,000:1
Viewing Angle (H/V): 178/178
Response Time: 8ms
V-Scanning Frequency: 48~75Hz
Contrast Ratio (Dynamic): Mega
Operation Time Support: 16/7
Maximum Pixel Frequency: 594MHz

Color Gamut: 72% (NTSC)
Glass Haze: 2 %
H-Scanning Frequency: 30~81kHz

Pixel Pitch (HxV) mm:-

(Size-43″): 0.245×0.245
(Size-50″): 0.285×0.285
(Size-55″): 0.315×0.315
(Size-65″): 0.372×0.372
(Size-75″): 0.429×0.429
(Size-85″): 0.487×0.487

Connectivity

HDMI In: 3
DP In: No
Version of HDMI: 2
Version of DP: No
Version of HDCP: 2.2
USB: 2
IR In: Yes
Audio In: No

Audio Out: Stereo Mini Jack
RS232 In: Yes
RS232 Out: Yes
RJ45 In: Yes
Wi-Fi: Yes
Bluetooth: Yes

Power

Power Supply: AC100-240V 50/60Hz
Power Consumption (Sleep Mode, W): 0.5

Power Consumption (On Mode, W): 214.5

Dimension

Set Dimension (WxHxD) mm:-

(Size-43″): 969.5 x 557.8 x 28.5
(Size-50″): 1124.1 x 644.8 x 28.5
(Size-55″): 1237.9 x 708.8 x 28.5‎
(Size-65″): 1456.8 x 831.9 x 28.5
(Size-75″): 1682.3 x 960.4 x 28.5
(Size-85″): 1904.3 x 1085.3 x 28.5

Package Dimension (WxHxD) mm:-

(Size-43″): 1093 x 667 x 126
(Size-50″): 1246 x 761 x 131
(Size-55″): 1403 x 835 x 148
(Size-65″): 1616 x 945 x 164
(Size-75″): 1839 x 1113 x 180
(Size-85″): 2077 x 1222 x 210

Weight

Set Weight:-

(Size-43″): 8.8 kg
(Size-50″): 11.8 kg
(Size-55″): 15.7 kg
(Size-65″): 21.5 kg
(Size-75″): 33.4 kg
(Size-85″): 41.9 kg

Package Weight:-

(Size-43″): 11.3 kg
(Size-50″): 14.9 kg
(Size-55″): 19.9 kg
(Size-65″): 28.0 kg
(Size-75″): 43.5 kg
(Size-85″): 53.9 kg

Operation Conditions

Temperature: 0 ℃ ~ 40 ℃

Humidity: 10 ~ 80%, non-condensing

Mechanical Specification

VESA Mount (mm):-

(Size-43″): 200 x 200
(Size-50″): 200 x 200
(Size-55″): 200 x 200
(Size-65″): 400 x 300
(Size-75″): 400 x 400
(Size-85″): 600 x 300

Frame Material: Non-Glossy

Bezel Width(mm):-

(Size-43″): 11.5
(Size-50″): 11.5
(Size-55″): 11.5
(Size-65″): 11.5
(Size-75″): 13.4
(Size-85″): 13.9

Optional Feature

Mount: WMN-B50SC

Stand: STN-L6585C

SoC

OS Version: Tizen 7.0

Flash Memory Size: 8GB

Eco

Energy Efficiency Class: A
